Adaptive Loudspeaker Integrate point Source

ALIS Series

The A.L.I.S. (Adaptive Loudspeaker Integrate point Source) is a high-Q arrayable speaker, suited for a wide range of applications. A.L.I.S. Series can be arrayed with a perfect coupling between array elements, avoiding comb filtering between horns. In this way single cabinets or pairs of cabinets can be used to deliver coverage only to desired areas, providing high SPL with perfect acoustic coupling.

A.L.I.S Series

A.L.I.S. have the advantage of offering a perfect control over horizontal coverage with minimal reflections on walls, or interactions with other parts of the sound system. The horizontal wavefront delivered by the enclosure allows uniform coverage in increments.

ALIS Series 1

ALIS 12

Arrayable Loudspeaker

♦ 2-way bi-amp Loudspeaker

♦ 1 x 12-inch LF + 1 x 1.4-inch HF compresion driver driver mounted on one waveguide coupled to a constant-directivity horn

Details
  • 2-Way Bi-amped Enclosure
  • 1 x 12-inch neodymium LF cone drive, vented box
  • 1 x 1.4-inch exit (3-inch voice coil) compression driver, attached to a waveguide.
ALIS Series 2

ALIS 15

Arrayable Loudspeaker

♦ 2-way bi-amp Loudspeaker

♦ 1 x 15-inch LF + 1 x 1.4-inch HF compresion driver driver mounted on a constant-directivity horn

Details
  • 2-Way Bi-amped Enclosure
  • 1 x 15-inch neodymium LF cone drive, vented box
  • 1 x 1.4-inch exit (3-inch voice coil) compression driver, attached to a CD Horn.

Point Source Loudspeakers

Scalable directivity

ALIS Series 3

High SPL

ALIS Series 4

Constant Curvature Enclosure

ALIS Series 5

Standalone or Distributed System

EASY-TO-USE RIGGING

ALIS Series 6

Premium WISA Birch Plywood. Best European Components

high-Q

high-Q arrayable speaker

ALIS Series 7

In the coupling plane the ALIS line sources yield a razor-sharp directivity pattern of 20º x 75º for ALIS12 and 40º x 75º for ALIS15.



The A.L.I.S. offer extremely easy-to-use rigging, making the system highly versatile. System’s performance is powerful enough to act as a main system, and at the same time versatile to serve in any number of supporting roles whether horizontal or vertical, flown or stacked applications are demanded.

ALIS Series 8

Arrayable Loudspeakers

ALIS Series 9

Horizontal or Vertical

High Directivity Control
