FULL-RANGE ULTRA-COMPACT LOUDSPEAKER

P204

2-Way Passive speaker

2 x 4-inch LF cone, Vented box

1 x 25mm soft dome tweeter

ibza-p204-tecnare-speaker-lateral-view

Power

80 W AES / 160 W continuos

Impedance

16 Ohms

SPL

111 dB continuos / 117 peak

Weight

4,5 kg.

The IBZA P204 is a 16 Ohm Ultra-Compact full range weatherproof plastic loudspeaker, designed to be used as a sound reinforcement speaker in a wide variety of audio applications.

The double high sensitivity 4” and the 25mm silk soft dome tweeter produce full range sound quality for foreground or background music, being voiced for maximum speech clarity and intelligibility.

The enclosure includes a special mounting bracket with an adjustable splay angle of 10° vertically.

The 3 support base provided by the flat bottom surface of the cabinet, allows also the speaker to be set on a surface such as a shelf.

Features

  • Ultra-Compact two-way system
  • 2 x 4-inch-LF/ 25mm dome tweeter
  • High-output, high-definition sound from an ultra-compact enclosure

Applications

  • Bars and restaurants
  • Stand alone system
  • Near-field applications
  • Background music in restaurant, disco, club.
Frequency Response 80 Hz – 20 kHz ± 4dB, measured on axys
Components 2 x 4-inch LF driver and 1 x 25 mm
Nominal Dispersions 120ºH x 120ºV @ 6dB point
Impedance:    16 Ohm
Axial Sensitivity: 92dB (1w/1m)
Calculated SPL: 111 dB continuous / 117 peak
Power Handling: 80 W AES / 160 W continuos
Dimensions (HxWxD) (millimeters/inches):  182 x 182 x 320 (mm) / 7.17″x 7.17″ x 12.60″
Net Weight (kg/Pounds): 4,5 kg. / 9.92 lbs
Construction:  Weatherproof plastic. Finished in Black or White
Grille Powder coated perforated steel with acoustically transparent reticulated foam
  • Accesories:

    ◊Colors Versions:
    -White color
    -Black color

    • U-Bracket included

Bars and restaurants

Stand alone system

Near-field applications

Background music in restaurant, disco, club.

















P204 Accessories

P204 Bracket
P204 Bracket

Bracket para colgar en pared el modelo P204. Permite un variado elenco de posiciones.
